    CNC bending presses

    TRUMPF and CoastOne producers guarantee high-quality bent parts of various sizes, as well as flexibility and the innovative instrumental capacity. Their attributes, such as ergonomics, comfortable and easy control, make the workflow significantly easier. The ram moves downwards in a controlled manner, in order to bend sheet metal. The sheet metal is pressed by the upper tool to V-shape lower tool of the matrix to be in straight and linear form. The rear stops provide the exact workpiece position.

    CNC bending presses

    TRUMPF and CoastOne producers guarantee high-quality bent parts of various sizes, as well as flexibility and the innovative instrumental capacity. Their attributes, such as ergonomics, comfortable and easy control, make the workflow significantly easier. The ram moves downwards in a controlled manner, in order to bend sheet metal. The sheet metal is pressed by the upper tool to V-shape lower tool of the matrix to be in straight and linear form. The rear stops provide the exact workpiece position.

    TRUMPF TruBend 7050

    We use the TruBend 7036 press brake for accurate and fast bending of small and medium-sized parts. Thanks to direct drive and automatic angle measurement systems, we achieve high productivity and quality. The working conditions for the operator are ergonomic when sitting or standing.

    The tool change process is fast and safe thanks to the BendGuard Automatic system. The CNC control also contributes to this, thanks to which the BendGuard Automatic device automatically moves to the height of the installed tools.

    Parameters

    Dimensions (L x W x H)

    2 420 x 1 805 x 2 580 mm

    Weight

    4 900 kg

    Press force

    500 kN

    Bending Length

    1 530 mm

    Width between columns

    1 305 mm

    Usable open height

    385 mm

    Throat depth

    250 mm

    Gallery
